Gate valve is a opening and closing part of the gate plate, the direction of motion of the gate plate is perpendicular to the direction of the fluid, the gate valve can only be fully opened and fully closed, can not be adjusted and throttled. Gate valves are sealed by the contact between the seat and the gate plate. Usually, the sealing surface will be surfacing with metal materials to increase the wear resistance, such as surfacing 1Cr13, STL6, stainless steel, etc. There are rigid gate and elastic gate, according to the different gate, gate valve is divided into rigid gate valve and elastic gate valve.
A weir-type diaphragm valve is a specific design of diaphragm valve that features a raised lip or saddle in the valve body. The diaphragm comes into contact with this weir to form a seal and control fluid flow. Main parts and materials Name/Material CI WCB CF8 CF3 CF8M CF3M Body CI WCB CF8 CF3 CF8M CF3M Diaphragm […]
A straight-through diaphragm valve controls fluid flow in a pipeline using a diaphragm that moves vertically to open or close the flow path. The straight-through design allows fluid to pass directly through the valve, reducing pressure drop and maintaining efficient flow. It is commonly used in applications where reliable sealing and minimal obstruction are needed, […]
A plug valve controls fluid flow in a pipeline using a cylindrical or tapered plug with a central hole. The plug rotates within the valve body to open or close the flow path. When the plug aligns with the pipeline, fluid passes through. When turned so the hole is perpendicular to the flow, it blocks […]
A fluorine lined control valve regulates the flow of fluids in a pipeline, adjusting flow rate, pressure, and temperature. It works by changing the size of the flow passage using elements like plugs, balls, or diaphragms. Control valves are crucial in industrial processes for maintaining operating conditions and ensuring system efficiency. They can be operated […]
